16 Port VGA KVM




Card image cap


Price : -

Technical Specification
  • - Model : IM-KVM0116
  • - Computer connections : 16
  • - Max connections : 512 (via cascade)
  • - Port selection : Pushbuttons, hot keys and OSD
  • - Connector : 16 x KVM port/ 1 x HDB-15 Female/ 1 x 6P Mini-Din F (purple)/ 1 x 6P Mini-Din F (green)/ 2 x USB port Cascade Port
  • - Cascade Port : 1 x HDB-15 Female
  • - Power input : 12 VDC, 0.5A
  • - Operating Temperature : 0 C to 40 C
  • - Storage Temperature : -20 C to 60 C
  • - Humidity : 0 to 80%RH (non condensing)
  • Card image cap
คุณสมบัติที่สำคัญ
  • - Access and control up to 16 computers from single USB or PS/2 console
  • - By daisy chaining up to 31 additional Combo-KVM
  • - As many as 512 computers can be controlled from a single keyboard mouse console
  • - Auto PS/2 and USB interface detection
  • - Designed for indoor and outdoor applications
  • - Support wireless keyboard and mouse from different suppliers
  • - Multiplatform support - Windows, Linux, Mac and Sun
  • - Auto scan feature for monitoring user-selected computers Easily to use and installation
  • - Hot pluggable (No software installation required)
